2 Megapixel License Plate Recognition Network Camera

Name: 2 Megapixel License Plate Recognition Network Camera
Brand: Pollo

1/2.8” CMOS Image Sensor · 1920 × 1080 Pixels Full HD Resolution · 0.0026 Lux Min. Illumination for Day Time Color View

Buying for your business? Apply for a trade account

Product overview

• 1/2.8” CMOS Image Sensor
• 1920 × 1080 Pixels Full HD Resolution
• 0.0026 Lux Min. Illumination for Day Time Color View
• 100-meter IR Night View Range
• Support License Plat Recognition
• Capacity of 10,000 Vehicle Plates
• Capturing Speed Range up to 70 kilometer per hour
• Motion Detection Alarm Trigger
• Line Crossing Detection
• Region Intrusion Detection
• Highlight Compensation for Image Correction
• Backlight Compensation for Image Correction
• ONVIF Protocol Supported
• IP67 Water & Dust Proofing
• PoE (IEEE802.3af)

Technical specifications

BLC	Yes
HLC	Yes
PoE	Yes, IEEE802.3af
ROI	Each ROI to be configured separately
Lens	7~22mm@F1.6, motorized
Audio	1CH audio input; 1CH audio output
Defog	Yes
Focus	motorized
Model	PLC-422M-LPR-IR10/PM
Reset	Yes
Network	RJ45
Storage	Network remote storage; micro-SD card storage
Bit Rate	64 Kbps ~ 6 Mbps
Iris Type	DC Iris
Digital NR	3D DNR
Image Size	1920 × 1080
Lens Mount	Φ14
Resolution	1080P (1920 × 1080), 720P (1280 × 720), D1, CIF, 480 × 240
Sub Stream	60Hz: 720P/D1/CIF/480x240 (1~30fps);
IR Distance	70~100m
Main Stream	60Hz: 1080P / 720P (1 ~ 30fps);50Hz: 1080P / 720P (1 ~ 25fps)
Smart Alarm	Motion detection, sensor alarm, SD card error, SD card full, IP address
Image Sensor	1 / 2.8" CMOS
Installation	Ceiling mounting; Wall mounting
Power Supply	DC12V/PoE
Video Output	No
Weight (net)	Approx. 1.04KG
Bit Rate Type	VBR / CBR
Image Settings	ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic,
Dimensions (mm)	279.5 × 100.3 × 88.9
Angle Adjustment	Pan: 0°~360°; Tilt:0°~80°; Rotation: 0°~360°
General Function	Watermark, IP address filtering, video mask, heartbeat, illegal login
Network Protocol	UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTMP, RTP, RTCP, ICMP, IGMP, PPPoE,
Min. Illumination	0.0026 lux@F1.2, AGC ON; 0 lux with IR
Online Connection	Support simultaneous monitoring for up to 4 users;
Power Consumption	< 11W
Remote Monitoring	Web browsing, CMS remote control
Electronic Shutter	1 / 3 s ~ 1 / 10000 s
Ingress Protection	IP67
Interface Protocol	ONVIF
Wide Dynamic Range	120dB
Intelligent Analytics	Video blur detection, video colour cast detection, scene change detection,
Operating Environment	- 30 °C ~ 60°C (-22 °F~140°F) E42Humidity: less than 95 % non condensing
